Energy Storage
Products
Energy Storage
Product Features
- Low maintenance & higher cycle life
- Low self discharge
- Robust Tubular with High Pressure die casted spine - resulting low rate of spine corrosion
- Excellent high purity, corrosion resistant alloy
- Spill Proof Vent plug - resulting in no spillage on top and low controlled acid fumes
- Level Indicator for easy maintenance
- Reliable and steady performance even on high load
Unique Features
- Advanced Tubular plate technology
- Thicker & Wider positive spine for very long life
- Special additives and optimized negative paste recipe for fast charge acceptance
- Special Grade PE Separators for low electrical resistance with High porosity
- MWCNT (Multi Wall Carbon Nano Tube) inside for improved electro chemical performance
TECHNICAL SPECIFICATIONS
| Model Name | Rated Capacity (Ah @C20) | Dry Weight (Kg ±2%) | Weight in KG ±2% | Container Type | Life Cycle @80% DOD | Dimensions in mm | Warranty | Backup @400 Watt | Loadability Per Container | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Length | Width | Height | |||||||||
| CBTT1000GEX | 100 | 22 | 51 | IT500 | 1300 | 502 | 188 | 410 | 24 Months | 2 Hours 45 Minutes | 400 |
| CBTT1008GEX | 120 | 24 | 55 | IT500 | 1300 | 502 | 188 | 410 | 24 Months | 3 Hours | 400 |
| CBTT1700GEX | 170 | 31.5 | 57 | IT500 | 1300 | 502 | 188 | 410 | 24 Months | 4 Hours | 400 |
| CBTT2000GEX | 200 | 36 | 60.5 | IT500 | 1300 | 502 | 188 | 410 | 24 Months | 5 Hours | 400 |
| CBTT2100GEX | 210 | 37 | 62 | IT500 | 1300 | 502 | 188 | 410 | 24 Months | 5 Hours 15 Minutes | 400 |
| CBTT2500GEX | 250 | 50.6 | 66 | IT500 | 1300 | 502 | 188 | 410 | 24 Months | 6 Hours 45 Minutes | 400 |
| CBTT3000GEX | 300 | 51.7 | 72 | IT500 | 1300 | 502 | 188 | 410 | 24 Months | 7 Hours | 380 |
| CBTT3500GEX | 330 | 54 | 79 | IT500 | 1300 | 502 | 188 | 410 | 24 Months | 7 Hours 30 Minutes | 360 |
