Motive Power Traction Battery
Product Features
- Advanced Flooded Tubular Technology
- Designed for Industrial & Traction Applications
- Imported Non-Woven Gauntlet with High Porosity
- Low Electrical Resistance & High Resilience
- Bolt-On Terminal Technology for Better Electrical Performance
- Prevents Terminal Wear & Tear
- Special Grommets Designed to Prevent Acid Seepage
- Enhanced Discharge Performance & Long Service Life
- Easy Maintenance & Replacement of Accessories
- Leakage Resistant Polypropylene Container & Lid
Battery Components
- Snaptop Vent Plug
- Terminal Post
- Polypropylene Lid
- Polypropylene Container
- Negative Pasted Plate
- Positive Spines
- Negative Grid
- Separator
- Gauntlet
- Mud Rib
Operation & Maintenance
- Do not discharge battery beyond 80% of nominal capacity
- Recharge immediately after discharge
- Use recommended traction taper chargers only
- Carry out equalizing charge every 2 weeks for heavy usage
- Keep battery top clean and dry
- Check earth leakage regularly
- Use battery grade water for topping-up
- Provide additional ventilation during charging
Typical IUI Recharge Method
- Step 1: @ 15% of rated C5 till 2.35 VPC
- Step 2: Constant Volt @ 2.35 VPC till current tapers to 7-8% of C5
- Step 3: @ 7-8% of C5 till voltage reaches 2.65 Volt per Cell
Technical Specifications
| Cell Type | Capacity AH@C5 | Length (MM) | Width (MM) | Dry Weight (KG) | Acid Volume (KG) | Filled Weight (KG) |
|---|---|---|---|---|---|---|
| Positive Plate Capacity 50 Ah, Overall Height 295MM, Height Upto Lid Top 270MM | ||||||
| 2 PzS 100 | 100 | 47 | 198 | 5.5 | 1.1 | 6.6 |
| 3 PzS 150 | 150 | 65 | 198 | 8 | 1.6 | 9.6 |
| 4 PzS 200 | 200 | 83 | 198 | 10.3 | 2.1 | 12.4 |
| 5 PzS 250 | 250 | 101 | 198 | 13.5 | 2.7 | 16.2 |
| 6 PzS 300 | 300 | 119 | 198 | 14.8 | 3.2 | 18 |
| 7 PzS 350 | 350 | 137 | 198 | 17 | 3.8 | 20.8 |
| 8 PzS 400 | 400 | 155 | 198 | 19.4 | 4.3 | 23.7 |
| 9 PzS 450 | 450 | 173 | 198 | 21.8 | 4.8 | 26.6 |
| 10 PzS 500 | 500 | 192 | 198 | 24.1 | 5.3 | 29.4 |
| Cell Type | Capacity AH@C5 | Length (MM) | Width (MM) | Dry Weight (KG) | Acid Volume (KG) | Filled Weight (KG) |
|---|---|---|---|---|---|---|
| Positive Plate Capacity 60 Ah, Overall Height 365MM, Height Upto Lid Top 340MM | ||||||
| 2 PzS 120 | 120 | 47 | 198 | 7 | 1.4 | 8.4 |
| 3 PzS 180 | 180 | 65 | 198 | 10 | 1.9 | 11.9 |
| 4 PzS 240 | 240 | 83 | 198 | 13 | 2.6 | 15.6 |
| 5 PzS 300 | 300 | 101 | 198 | 15.7 | 3.3 | 19 |
| 6 PzS 360 | 360 | 119 | 198 | 18.5 | 3.9 | 22.4 |
| 7 PzS 420 | 420 | 137 | 198 | 21.5 | 4.5 | 26 |
| 8 PzS 480 | 480 | 155 | 198 | 24.5 | 5.1 | 29.6 |
| 9 PzS 540 | 540 | 173 | 198 | 26.6 | 5.8 | 32.4 |
| 10 PzS 600 | 600 | 192 | 198 | 30.7 | 6.3 | 37 |
